دیتاشیت LT8650SIV#PBF
مشخصات دیتاشیت
| نام دیتاشیت |
LT8650S
|
| حجم فایل |
1437.764
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
32
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
Step-down type
-
Topology:
Step-down
-
Datasheet:
Analog Devices LT8650SIV#PBF
-
Output Type:
Adjustable
-
Input Voltage:
3V~42V
-
Number of Outputs:
2
-
Switching Frequency:
3MHz
-
Output Current (Max):
4A
-
Operating Temperature:
-40°C~+125°C@(TJ)
-
Synchronous Rectification:
NO
-
Package:
LQFN-32-EP(4x6)
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Tray
-
Part Status:
Active
-
Output Configuration:
Positive
-
Voltage - Input (Min):
3V
-
Voltage - Input (Max):
42V
-
Voltage - Output (Min/Fixed):
3.3V, 5V
-
Voltage - Output (Max):
-
-
Current - Output:
4A
-
Frequency - Switching:
300kHz ~ 3MHz
-
Synchronous Rectifier:
No
-
Mounting Type:
Surface Mount
-
Package / Case:
32-TFQFN Exposed Pad, 28 Leads
-
Supplier Device Package:
32-LQFN (6x4)
-
Base Part Number:
LT8650
-
detail:
Buck Switching Regulator IC Positive Fixed 3.3V, 5V 2 Output 4A 32-TFQFN Exposed Pad, 28 Leads
