HI3-0201HS-5 数据手册
其他文档
未找到其他文档！
技术规格
- Multiplexer/Demultiplexer Circuit: 1:1
- Part Status: Obsolete
- Charge Injection: 10pC
- -3db Bandwidth: -
- Operating Temperature: 0°C ~ 70°C (TA)
- Voltage - Supply, Dual (V±): ±5V ~ 20V
- Supplier Device Package: 16-PDIP
- Package / Case: 16-DIP (0.300", 7.62mm)
- Switch Time (Ton, Toff) (Max): 50ns, 50ns
- Packaging: Tube
- Channel-to-Channel Matching (ΔRon): -
- Voltage - Supply, Single (V+): 12V ~ 20V
- Channel Capacitance (CS(off), CD(off)): 10pF, 10pF
- Switch Circuit: SPST - NC
- Mounting Type: Through Hole
- Series: -
- Crosstalk: -90dB @ 100kHz
- Number of Circuits: 4
- Manufacturer: Maxim Integrated
- Current - Leakage (IS(off)) (Max): 1nA
- Base Part Number: HI3-0201
- On-State Resistance (Max): 50Ohm
- detail: 4 Circuit IC Switch 1:1 50Ohm 16-PDIP
