LTC3607IUD#PBF دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت LTC3607IUD#PBF	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Step-down type
Topology: Step-down
Datasheet: Analog Devices LTC3607IUD#PBF
Output Type: Adjustable
Input Voltage: 4.5V~15V
Output Voltage: 0.6V~15V
Number of Outputs: 2
Switching Frequency: 2.25MHz
Output Current (Max): 600mA
Operating Temperature: -40°C~+125°C@(TJ)
Synchronous Rectification: Yes
Package: QFN-16-EP(3x3)
Manufacturer: Analog Devices
Series: -
Packaging: Tube
Part Status: Active
Output Configuration: Positive
Voltage - Input (Min): 4.5V
Voltage - Input (Max): 15V
Voltage - Output (Min/Fixed): 0.6V
Voltage - Output (Max): 15V
Current - Output: 600mA
Frequency - Switching: 2.25MHz
Synchronous Rectifier: Yes
Mounting Type: Surface Mount
Package / Case: 16-WFQFN Exposed Pad
Supplier Device Package: 16-QFN (3x3)
Base Part Number: LTC3607
detail: Buck Switching Regulator IC Positive Adjustable 0.6V 2 Output 600mA 16-WFQFN Exposed Pad
