LTM4646EY#PBF دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت LTM4646EY#PBF	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/Power Modules
Datasheet: Analog Devices LTM4646EY#PBF
Output Channel: 2
Output Voltage: 0.6V~5.5V
Input Voltage(DC): 4.5V~20V
Output Current (Max): 10A
Conversion Efficiency: 96%
Package: BGA-88
Manufacturer: Analog Devices
Series: LTM®, uModule®
Part Status: Active
Type: Non-Isolated PoL Module
Number of Outputs: 2
Voltage - Input (Min): 4.5V
Voltage - Input (Max): 20V
Voltage - Output 1: 0.6 ~ 5.5V
Voltage - Output 2: 0.6 ~ 5.5V
Voltage - Output 3: -
Voltage - Output 4: -
Current - Output (Max): 10A, 10A
Applications: ITE (Commercial)
Features: OCP, OVP, SCP, UVLO
Operating Temperature: -40°C ~ 125°C
Efficiency: 96%
Mounting Type: Surface Mount
Package / Case: 88-BBGA Module
Size / Dimension: 0.59" L x 0.44" W x 0.21" H (15.0mm x 11.3mm x 5.2mm)
Supplier Device Package: 88-BGA (15x11.25)
Base Part Number: LTM4646
detail: Non-Isolated PoL Module DC DC Converter 2 Output 0.6 ~ 5.5V 0.6 ~ 5.5V 10A, 10A 4.5V - 20V Input
