LTC3535EDD#PBF دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت LTC3535EDD#PBF	دانلود دیتاشیت

LTC3535 16 pages

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: boost converterType
Topology: Boost
Datasheet: Analog Devices LTC3535EDD#PBF
Output Type: Adjustable
Input Voltage: 0.5V~5V
Output Voltage: 1.5V~5.25V
Number of Outputs: 2
Switching Frequency: 1MHz
Output Current (Max): 550mA
Operating Temperature: -40°C~+85°C@(TA)
Synchronous Rectification: Yes
Package: DFN-12(3x3)
Manufacturer: Analog Devices
Series: -
Packaging: Tube
Part Status: Active
Output Configuration: Positive
Voltage - Input (Min): 0.5V
Voltage - Input (Max): 5V
Voltage - Output (Min/Fixed): 1.5V
Voltage - Output (Max): 5.25V
Current - Output: 550mA (Switch)
Frequency - Switching: 1MHz
Synchronous Rectifier: Yes
Mounting Type: Surface Mount
Package / Case: 12-WFDFN Exposed Pad
Supplier Device Package: 12-DFN (3x3)
Base Part Number: LTC3535
detail: Boost Switching Regulator IC Positive Adjustable 1.5V 2 Output 550mA (Switch) 12-WFDFN Exposed Pad
