LT1072CS8#PBF 数据手册
其他文档
LT1072 Datasheet 16 pages
技术规格
- RoHS: true
- Category: Power Supply Chip/AC-DC Controllers & Regulators
- Datasheet: Analog Devices LT1072CS8#PBF
- Package: SOP-8
- Manufacturer: Analog Devices
- Series: -
- Packaging: Tube
- Part Status: Active
- Function: Step-Up, Step-Down, Step-Up/Step-Down
- Output Configuration: Positive or Negative
- Topology: Buck, Boost, Cuk, Flyback, Forward Converter
- Output Type: Adjustable
- Number of Outputs: 1
- Voltage - Input (Min): 3V
- Voltage - Input (Max): 40V
- Voltage - Output (Min/Fixed): 1.25V
- Voltage - Output (Max): 60V (Switch)
- Current - Output: 1.25A (Switch)
- Frequency - Switching: 40kHz
- Synchronous Rectifier: No
- Operating Temperature: 0°C ~ 100°C (TJ)
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: 8-SOIC
- Base Part Number: LT1072
- detail: Buck, Boost, Cuk, Flyback, Forward Converter Switching Regulator IC Positive or Negative Adjustable 1.25V 1 Output 1.25A (Switch) 8-SOIC (0.154", 3.90mm Width)
