DS87C550-QNL Datasheet
Datasheet specifications
| Datasheet's name | DS87C550 |
|---|---|
| File size | 683.811 KB |
| File type | |
| Number of pages | 49 |
Download Datasheet DS87C550 |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Program Memory Type: OTP
- Part Status: Obsolete
- Speed: 33MHz
- RAM Size: 1K x 8
- Data Converters: A/D 6x10b
- Operating Temperature: -40°C ~ 85°C (TA)
- Series: 87C
- Supplier Device Package: 68-PLCC (24.23x24.23)
- Package / Case: 68-LCC (J-Lead)
- Packaging: Tube
- Number of I/O: 55
- Core Processor: 8051
- Core Size: 8-Bit
- EEPROM Size: -
- Connectivity: EBI/EMI, SIO, UART/USART
- Mounting Type: Surface Mount
- Oscillator Type: External
- Program Memory Size: 8KB (8K x 8)
- Peripherals: Power-Fail Reset, PWM, WDT
- Manufacturer: Maxim Integrated
- Base Part Number: DS87C550
- Voltage - Supply (Vcc/Vdd): 4.5V ~ 5.5V
- detail: 8051 87C Microcontroller IC 8-Bit 33MHz 8KB (8K x 8) OTP 68-PLCC (24.23x24.23)
