دیتاشیت LTC3805EMSE-5#PBF

مشخصات دیتاشیت

دانلود دیتاشیت LTC3805-5 Datasheet	LTC3805-5 Datasheet Datasheet

Manufacturer: Linear Technology/Analog Devices
Series: -
Packaging: Tube
Part Status: Active
Output Type: Transistor Driver
Function: Step-Up, Step-Up/Step-Down
Output Configuration: Positive, Isolation Capable
Topology: Boost, Flyback, SEPIC
Number of Outputs: 1
Output Phases: 1
Voltage - Supply (Vcc/Vdd): 3.95V ~ 9.5V
Frequency - Switching: 70kHz ~ 700kHz
Duty Cycle (Max): 80%
Synchronous Rectifier: No
Clock Sync: Yes
Serial Interfaces: -
Control Features: Enable, Soft Start
Operating Temperature: -40°C ~ 85°C (TA)
Mounting Type: Surface Mount
Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width) Exposed Pad
Supplier Device Package: 10-MSOP-EP
Base Part Number: LTC3805
detail: Boost, Flyback, SEPIC Regulator Positive, Isolation Capable Output Step-Up, Step-Up/Step-Down DC-DC Controller IC 10-MSOP-EP
