DS1803Z-010/T&R Datasheet
Datasheet specifications
| Datasheet's name | DS1803 |
|---|---|
| File size | 305.842 KB |
| File type | |
| Number of pages | 11 |
Download Datasheet DS1803 |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Temperature Coefficient (Typ): 750ppm/°C
- Features: Selectable Address
- Supplier Device Package: 16-SO
- Configuration: Potentiometer
- Resistance (Ohms): 10k
- Tolerance: ±20%
- Package / Case: 16-SOIC (0.154", 3.90mm Width)
- Resistance - Wiper (Ohms) (Typ): 400
- Part Status: Obsolete
- Voltage - Supply: 2.7V ~ 5.5V
- Operating Temperature: -40°C ~ 85°C
- Number of Taps: 256
- Series: -
- Interface: I²C
- Taper: Linear
- Mounting Type: Surface Mount
- Number of Circuits: 2
- Packaging: Tape & Reel (TR)
- Memory Type: Volatile
- Base Part Number: DS1803
- Manufacturer: Maxim Integrated
- detail: Digital Potentiometer 10k Ohm 2 Circuit 256 Taps I²C Interface 16-SO
