دیتاشیت LT1959CS8#TRPBF
مشخصات دیتاشیت
| نام دیتاشیت |
LT1959
|
| حجم فایل |
304.833
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
24
|
مشخصات
-
Manufacturer:
Linear Technology/Analog Devices
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Function:
Step-Down
-
Output Configuration:
Positive
-
Topology:
Buck, SEPIC
-
Output Type:
Adjustable
-
Number of Outputs:
1
-
Voltage - Input (Min):
4.3V
-
Voltage - Input (Max):
15V
-
Voltage - Output (Min/Fixed):
1.21V
-
Voltage - Output (Max):
12.9V
-
Current - Output:
4.5A (Switch)
-
Frequency - Switching:
500kHz
-
Synchronous Rectifier:
No
-
Operating Temperature:
0°C ~ 125°C (TJ)
-
Mounting Type:
Surface Mount
-
Package / Case:
8-SOIC (0.154", 3.90mm Width)
-
Supplier Device Package:
8-SOIC
-
Base Part Number:
LT1959
-
detail:
Buck, SEPIC Switching Regulator IC Positive Adjustable 1.21V 1 Output 4.5A (Switch) 8-SOIC (0.154", 3.90mm Width)
