دیتاشیت DG405DY

DG401/03/05

مشخصات دیتاشیت

نام دیتاشیت DG401/03/05
حجم فایل 94.431 کیلوبایت
نوع فایل pdf
تعداد صفحات 8

دانلود دیتاشیت DG401/03/05

DG401/03/05 Datasheet

مشخصات

  • Multiplexer/Demultiplexer Circuit: 2:1
  • Part Status: Obsolete
  • Charge Injection: 10pC
  • -3db Bandwidth: -
  • Operating Temperature: 0°C ~ 70°C (TA)
  • Voltage - Supply, Dual (V±): ±4.5V ~ 20V
  • Supplier Device Package: 16-SO
  • Package / Case: 16-SOIC (0.154", 3.90mm Width)
  • Switch Time (Ton, Toff) (Max): 150ns, 100ns
  • Packaging: Tube
  • Channel-to-Channel Matching (ΔRon): 500mOhm
  • Voltage - Supply, Single (V+): 10V ~ 30V
  • Channel Capacitance (CS(off), CD(off)): 12pF, 12pF
  • Switch Circuit: DPST - NO
  • Mounting Type: Surface Mount
  • Series: -
  • Crosstalk: -90dB @ 1MHz
  • Number of Circuits: 2
  • Manufacturer: Maxim Integrated
  • Current - Leakage (IS(off)) (Max): 500pA
  • Base Part Number: DG405
  • On-State Resistance (Max): 45Ohm
  • detail: 2 Circuit IC Switch 2:1 45Ohm 16-SO
