دیتاشیت LT8471HFE#PBF
مشخصات دیتاشیت
| نام دیتاشیت | LT8471 Datasheet |
|---|---|
| حجم فایل | 488.424 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 36 |
دانلود دیتاشیت LT8471 Datasheet |
LT8471 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: boost converterType;Step-down type;Buck-boost type
- Topology: Step-down;Boost;Flyback;SEPIC
- Datasheet: Analog Devices LT8471HFE#PBF
- Output Type: Adjustable
- Input Voltage: 2.6V~50V
- Output Voltage: 2.6V~50V
- Number of Outputs: 2
- Switching Frequency: 2MHz
- Output Current (Max): 1.35A;2.1A
- Operating Temperature: -40°C~+150°C@(TJ)
- Synchronous Rectification: NO
- Package: TSSOP-20-EP
- Manufacturer: Analog Devices
- Series: -
- Packaging: Tube
- Part Status: Active
- Output Configuration: Positive or Negative
- Voltage - Input (Min): 2.6V
- Voltage - Input (Max): 50V
- Voltage - Output (Min/Fixed): 2.6V
- Voltage - Output (Max): 50V (Switch)
- Current - Output: 1.35A (Switch), 2.1A (Switch)
- Frequency - Switching: 100kHz ~ 2MHz
- Synchronous Rectifier: No
- Mounting Type: Surface Mount
- Package / Case: 20-TSSOP (0.173", 4.40mm Width) Exposed Pad
- Supplier Device Package: 20-TSSOP-EP
- Base Part Number: LT8471
- detail: Buck, Boost, Flyback, SEPIC Switching Regulator IC Positive or Negative Adjustable 2.6V 2 Output 1.35A (Switch), 2.1A (Switch) 20-TSSOP (0.173", 4.40mm Width) Exposed Pad
