AT89C5131A-S3SUL دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | AT89C5131A-S3SUL |
|---|---|
| حجم فایل | 86.711 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 186 |
دانلود دیتاشیت AT89C5131A-S3SUL |
دانلود دیتاشیت |
|---|
سایر مستندات
AT89C5131A-L 186 pages
AT89C5131A-L Errata 4 pages
مشخصات فنی
- RoHS: true
- EEPROM: 32KB
- CPU Core: 51Series
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: 1.25KB
- Watchdog: Yes
- ADC (Bit): -
- DAC (Bit): -
- Datasheet: Microchip Tech AT89C5131A-S3SUL
- PWM (Bit): -
- LED Module: Yes
- Real-Time Clock: -
- CPU Maximum Speed: 48MHz
- GPIO Ports Number: 34
- Low-Voltage Detect: Yes
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: PWM;WDT
- Program Memory Type: FLASH
- Direct Memory Access: -
- Program Storage Size: 32KB
- Universal Serial Bus: Yes
- communication protocol: -
- Operating Voltage Range: 3V~3.6V
- Infrared Data Association: -
- Operating Temperature Range: -40°C~+85°C
- Secure Digital Input and Output: -
- Package: PLCC-52
- Manufacturer: Microchip Tech
- Series: AT89C513x
- Packaging: Tube
- Part Status: Active
- Core Processor: 80C51
- Core Size: 8-Bit
- Speed: 48MHz
- Connectivity: I²C, SPI, UART/USART, USB
- Peripherals: LED, POR, PWM, WDT
- Number of I/O: 34
- Program Memory Size: 32KB (32K x 8)
- EEPROM Size: 4K x 8
- Voltage - Supply (Vcc/Vdd): 3V ~ 3.6V
- Data Converters: -
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 52-LCC (J-Lead)
- Supplier Device Package: 52-PLCC (19.15x19.15)
- Base Part Number: AT89C5131
- detail: 80C51 AT89C513x Microcontroller IC 8-Bit 48MHz 32KB (32K x 8) FLASH 52-PLCC (19.15x19.15)
