دیتاشیت ATMEGA64RFR2-ZUR
مشخصات دیتاشیت
| نام دیتاشیت | ATmega256/128/64RFR2 Datasheet |
|---|---|
| حجم فایل | 5532.575 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 611 |
دانلود دیتاشیت ATmega256/128/64RFR2 Datasheet |
ATmega256/128/64RFR2 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Radio Frequency Chip/Antenna/RF Transceiver ICs
- Data Rate: 2Mbps
- Datasheet: Microchip Tech ATMEGA64RFR2-ZUR
- Interface: I2C,JTAG,SPI,USART
- Applications: 802.15.4
- Frequency Range: 2.4GHz
- Receive Current: 5mA
- Operating Voltage: 1.8V~3.6V
- Operating Temperature: -40°C~+85°C
- Current Of Transmitting: 8mA
- Package: QFN-64-EP(9x9)
- Manufacturer: Microchip Tech
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Type: TxRx + MCU
- RF Family/Standard: 802.15.4
- Protocol: Zigbee®
- Modulation: DSSS, O-QPSK
- Frequency: 2.4GHz
- Data Rate (Max): 2Mbps
- Power - Output: 3.5dBm
- Sensitivity: -100dBm
- Memory Size: 64kB Flash, 2kB EEPROM, 8kB SRAM
- Serial Interfaces: I²C, JTAG, SPI, USART
- GPIO: 35
- Voltage - Supply: 1.8V ~ 3.6V
- Current - Receiving: 5mA ~ 12.5mA
- Current - Transmitting: 8mA ~ 14.5mA
- Mounting Type: Surface Mount
- Package / Case: 64-VFQFN Exposed Pad
- Supplier Device Package: 64-QFN (9x9)
- Base Part Number: ATMEGA64RFR2
- detail: IC RF TxRx + MCU 802.15.4 Zigbee® 2.4GHz 64-VFQFN Exposed Pad
