دیتاشیت LTC2320CUKG-12#PBF

LTC2320-12 Datasheet

مشخصات دیتاشیت

نام دیتاشیت LTC2320-12 Datasheet
حجم فایل 1226.892 کیلوبایت
نوع فایل pdf
تعداد صفحات 32

دانلود دیتاشیت LTC2320-12 Datasheet

LTC2320-12 Datasheet Datasheet

مشخصات

  • RoHS: true
  • Category: ADC/DAC/Data Conversion/Analog To Digital Converters (ADCs)
  • Datasheet: Analog Devices LTC2320CUKG-12#PBF
  • Interface: Parallel;SPI
  • resolution: 12Bit
  • Supply Voltage: 3.13V~3.47V;5V
  • differential input: Yes
  • number of channels: 8
  • sampling frequency: 1.5MHz
  • Operating Temperature: 0°C~+70°C
  • Package: QFN-52-EP(7x8)
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Number of Bits: 12
  • Sampling Rate (Per Second): 1.5M
  • Number of Inputs: 8
  • Input Type: Differential
  • Data Interface: LVDS - Parallel, SPI
  • Configuration: S/H-MUX-ADC
  • Ratio - S/H:ADC: 2:1
  • Number of A/D Converters: 4
  • Architecture: SAR
  • Reference Type: External, Internal
  • Voltage - Supply, Analog: 3.13V ~ 3.47V, 5V
  • Voltage - Supply, Digital: 3.13V ~ 3.47V, 5V
  • Features: Simultaneous Sampling
  • Package / Case: 52-WFQFN Exposed Pad
  • Supplier Device Package: 52-QFN (7x8)
  • Mounting Type: Surface Mount
  • Base Part Number: LTC2320
  • detail: 12 Bit Analog to Digital Converter 8 Input 4 SAR 52-QFN (7x8)
