دیتاشیت AT91M40800-33AU-999

مشخصات دیتاشیت

دانلود دیتاشیت AT91M40800 Summary	AT91M40800 Summary Datasheet

RoHS: true
CPU Core: ARMOther series
Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
Watchdog: Yes
Datasheet: Microchip Tech AT91M40800-33AU-999
CPU Maximum Speed: 33MHz
GPIO Ports Number: 32
Low-Voltage Detect: Yes
Operating Voltage Range: 1.8V~3.6V
Operating Temperature Range: -40°C~+85°C
Package: LQFP-100(14x14)
Manufacturer: Microchip Tech
Series: AT91
Packaging: Cut Tape (CT)
Part Status: Discontinued at Digi-Key
Core Processor: ARM7®
Core Size: 16/32-Bit
Speed: 33MHz
Connectivity: EBI/EMI, UART/USART
Peripherals: POR, WDT
Number of I/O: 32
Program Memory Size: -
Program Memory Type: ROMless
EEPROM Size: -
RAM Size: 8K x 8
Voltage - Supply (Vcc/Vdd): 1.8V ~ 3.6V
Data Converters: -
Oscillator Type: External
Operating Temperature: -40°C ~ 85°C (TA)
Mounting Type: Surface Mount
Package / Case: 100-LQFP
Supplier Device Package: 100-LQFP (14x14)
Base Part Number: AT91M40800
detail: ARM7® AT91 Microcontroller IC 16/32-Bit 33MHz ROMless 100-LQFP (14x14)
