دیتاشیت LT3083IT#PBF

LT3083 Datasheet

مشخصات دیتاشیت

نام دیتاشیت LT3083 Datasheet
حجم فایل 416.5 کیلوبایت
نوع فایل pdf
تعداد صفحات 28

دانلود دیتاشیت LT3083 Datasheet

LT3083 Datasheet Datasheet

مشخصات

  • Manufacturer: Linear Technology/Analog Devices
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Output Configuration: Positive
  • Output Type: Adjustable
  • Number of Regulators: 1
  • Voltage - Input (Max): 23V
  • Voltage - Output (Min/Fixed): 0V
  • Voltage - Output (Max): 23V
  • Voltage Dropout (Max): 0.51V @ 3A
  • Current - Output: 3A
  • Current - Quiescent (Iq): 50.5µA
  • Current - Supply (Max): 1mA
  • PSRR: 85dB ~ 20dB (120Hz ~ 1MHz)
  • Control Features: -
  • Protection Features: Over Current, Over Temperature, Short Circuit
  • Operating Temperature: -40°C ~ 125°C
  • Mounting Type: Through Hole
  • Package / Case: TO-220-5 Formed Leads
  • Supplier Device Package: TO-220-5
  • Base Part Number: LT3083
  • detail: Linear Voltage Regulator IC 1 Output 3A TO-220-5
