دیتاشیت LT1071CT#PBF

مشخصات دیتاشیت

دانلود دیتاشیت LT1070, LT1071 Datasheet	LT1070, LT1071 Datasheet Datasheet

Manufacturer: Linear Technology/Analog Devices
Series: -
Packaging: Tube
Part Status: Active
Function: Step-Up, Step-Down, Step-Up/Step-Down
Output Configuration: Positive or Negative
Topology: Buck, Boost, Cuk, Flyback, Forward Converter
Output Type: Adjustable
Number of Outputs: 1
Voltage - Input (Min): 3V
Voltage - Input (Max): 60V
Voltage - Output (Min/Fixed): 1.25V
Voltage - Output (Max): 65V (Switch)
Current - Output: 2.5A (Switch)
Frequency - Switching: 40kHz
Synchronous Rectifier: No
Operating Temperature: 0°C ~ 100°C (TJ)
Mounting Type: Through Hole
Package / Case: TO-220-5 Formed Leads
Supplier Device Package: TO-220-5
Base Part Number: LT1071
detail: Buck, Boost, Cuk, Flyback, Forward Converter Switching Regulator IC Positive or Negative Adjustable 1.25V 1 Output 2.5A (Switch) TO-220-5 Formed Leads
