LTM2882 Datasheet Datasheet

LTM2882 Datasheet

Datasheet specifications

Datasheet's name LTM2882 Datasheet
File size 658.359 KB
File type pdf
Number of pages 22

Download Datasheet LTM2882 Datasheet

Download Datasheet

Other documentations

LTM2882CY-5#PBF 22 pages

Technical specifications

  • RoHS: true
  • Category: Communication Interface Chip/UART/485/232/Digital Isolators
  • Data Rate: 10Mbps
  • Datasheet: Analog Devices LTM2882CV-3#PBF
  • Applications: RS232
  • Supply Voltage: 3V~3.6V
  • Forward Channel: 2
  • Reverse channel: 2
  • Number of Channels: 4
  • Isolation Technology: Magnetic isolation
  • Operating Temperature: 0°C~+70°C
  • Voltage Isolation or Not: 带电压隔离
  • Package: LGA-32
  • Manufacturer: Analog Devices
  • Series: µModule®
  • Packaging: Tray
  • Part Status: Active
  • Technology: Magnetic Coupling
  • Type: RS232
  • Isolated Power: Yes
  • Inputs - Side 1/Side 2: 2/2
  • Channel Type: Unidirectional
  • Voltage - Isolation: 2500Vrms
  • Common Mode Transient Immunity (Min): 30kV/µs
  • Propagation Delay tpLH / tpHL (Max): 100ns, 100ns
  • Pulse Width Distortion (Max): -
  • Rise / Fall Time (Typ): 60ns, 60ns
  • Voltage - Supply: 3V ~ 3.6V
  • Mounting Type: Surface Mount
  • Package / Case: 32-BLGA
  • Supplier Device Package: 32-LGA (15x11.25)
  • Base Part Number: LTM2882
  • detail: RS232 Digital Isolator 2500Vrms 4 Channel 10Mbps 30kV/µs CMTI 32-BLGA
