MAX4514EUK-T Datasheet
Datasheet specifications
| Datasheet's name | MAX4514EUK-T |
|---|---|
| File size | 405.955 KB |
| File type | |
| Number of pages | 8 |
Download Datasheet MAX4514EUK-T |
Download Datasheet |
|---|
Other documentations
Part Numbering System 7 pages
MAX4514-15 8 pages
Technical specifications
- Multiplexer/Demultiplexer Circuit: 1:1
- Part Status: Obsolete
- Charge Injection: 2pC
- -3db Bandwidth: -
- Operating Temperature: -40°C ~ 85°C (TA)
- Voltage - Supply, Dual (V±): -
- Supplier Device Package: SOT-23-5
- Package / Case: SC-74A, SOT-753
- Switch Time (Ton, Toff) (Max): 150ns, 100ns
- Packaging: Tape & Reel (TR)
- Channel-to-Channel Matching (ΔRon): -
- Voltage - Supply, Single (V+): 2V ~ 12V
- Channel Capacitance (CS(off), CD(off)): 14pF, 14pF
- Switch Circuit: SPST - NO
- Mounting Type: Surface Mount
- Series: -
- Crosstalk: -
- Number of Circuits: 1
- Manufacturer: Maxim Integrated
- Current - Leakage (IS(off)) (Max): 1nA
- Base Part Number: MAX4514
- On-State Resistance (Max): 20Ohm
- detail: 1 Circuit IC Switch 1:1 20Ohm SOT-23-5
