دیتاشیت LT1308ACS8#TRPBF
مشخصات دیتاشیت
| نام دیتاشیت | LT1308A, LT1308B Datasheet |
|---|---|
| حجم فایل | 380.727 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 20 |
دانلود دیتاشیت LT1308A, LT1308B Datasheet |
LT1308A, LT1308B Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: boost converterType;Buck-boost type
- Topology: Boost;SEPIC
- Output Type: Adjustable
- Input Voltage: 1V~10V
- Output Voltage: 1.22V~34V
- Number of Outputs: 1
- Switching Frequency: 600kHz
- Output Current (Max): 2A
- Operating Temperature: 0°C~+70°C@(TA)
- Synchronous Rectification: NO
- Package: SOP-8
- Manufacturer: Analog Devices
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Output Configuration: Positive
- Voltage - Input (Min): 1V
- Voltage - Input (Max): 10V
- Voltage - Output (Min/Fixed): 1.22V
- Voltage - Output (Max): 34V
- Current - Output: 2A (Switch)
- Frequency - Switching: 600kHz
- Synchronous Rectifier: No
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: 8-SOIC
- Base Part Number: LT1308
- detail: Boost, SEPIC Switching Regulator IC Positive Adjustable 1.22V 1 Output 2A (Switch) 8-SOIC (0.154", 3.90mm Width)
