دیتاشیت AT89C5115-RATUM
مشخصات دیتاشیت
| نام دیتاشیت |
A(T)89C5115
|
| حجم فایل |
1098.441
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
113
|
مشخصات
-
RoHS:
true
-
CPU Core:
51Series
-
Category:
Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
-
Watchdog:
Yes
-
ADC (Bit):
10bit
-
Datasheet:
Microchip Tech AT89C5115-RATUM
-
CPU Maximum Speed:
40MHz
-
GPIO Ports Number:
20
-
Low-Voltage Detect:
Yes
-
Program Storage Size:
16KB
-
Operating Voltage Range:
3V~5.5V
-
Operating Temperature Range:
-40°C~+85°C
-
Package:
QFP-32(7x7)
-
Manufacturer:
Microchip Tech
-
Series:
89C
-
Packaging:
Tray
-
Part Status:
Active
-
Core Processor:
80C51
-
Core Size:
8-Bit
-
Speed:
40MHz
-
Connectivity:
UART/USART
-
Peripherals:
POR, PWM, WDT
-
Number of I/O:
20
-
Program Memory Size:
16KB (16K x 8)
-
Program Memory Type:
FLASH
-
EEPROM Size:
2K x 8
-
RAM Size:
512 x 8
-
Voltage - Supply (Vcc/Vdd):
3V ~ 5.5V
-
Data Converters:
A/D 8x10b
-
Oscillator Type:
External
-
Operating Temperature:
-40°C ~ 85°C (TA)
-
Mounting Type:
Surface Mount
-
Package / Case:
32-LQFP
-
Supplier Device Package:
32-VQFP (7x7)
-
Base Part Number:
AT89C5115
-
detail:
80C51 89C Microcontroller IC 8-Bit 40MHz 16KB (16K x 8) FLASH 32-VQFP (7x7)
