- دیتاشیت DSPIC30F5015T-30I/PT
دیتاشیت DSPIC30F5015T-30I/PT
مشخصات دیتاشیت
| نام دیتاشیت | DSPIC30F5015, 5016 Data Sheet |
|---|---|
| حجم فایل | 3312.681 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 234 |
دانلود دیتاشیت DSPIC30F5015, 5016 Data Sheet |
DSPIC30F5015, 5016 Data Sheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Single Chip Microcomputer/Microcontroller/Digital Signal Processors / Controllers (DSPs/DSCs)
- Datasheet: Microchip Tech DSPIC30F5015T-30I/PT
- FLASH Size: 66KB
- GPIO Ports Number: 52
- Supply Voltage Range: 2.5V~5.5V
- Operating Temperature Range: -40°C~+85°C
- Package: TQFP-64(10x10)
- Manufacturer: Microchip Tech
- Series: dsPIC™ 30F
- Packaging: Tape & Reel (TR)
- Part Status: Active
- Core Processor: dsPIC
- Core Size: 16-Bit
- Speed: 30 MIPs
- Connectivity: CANbus, I²C, SPI, UART/USART
- Peripherals: Brown-out Detect/Reset, Motor Control PWM, QEI, POR, PWM, WDT
- Number of I/O: 52
- Program Memory Size: 66KB (22K x 24)
- Program Memory Type: FLASH
- EEPROM Size: 1K x 8
- RAM Size: 2K x 8
- Voltage - Supply (Vcc/Vdd): 2.5V ~ 5.5V
- Data Converters: A/D 16x10b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 64-TQFP
- Supplier Device Package: 64-TQFP (10x10)
- Base Part Number: DSPIC30F5015
- detail: dsPIC dsPIC™ 30F Microcontroller IC 16-Bit 30 MIPs 66KB (22K x 24) FLASH 64-TQFP (10x10)
