دیتاشیت LT1949ES8#PBF
مشخصات دیتاشیت
| نام دیتاشیت |
LT1949
|
| حجم فایل |
171.381
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
8
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
boost converterType;Buck-boost type
-
Topology:
Boost;SEPIC
-
Datasheet:
Analog Devices LT1949ES8#PBF
-
Output Type:
Adjustable
-
Input Voltage:
1.7V~12V
-
Output Voltage:
1.7V~28V
-
Number of Outputs:
1
-
Switching Frequency:
600kHz
-
Output Current (Max):
1A
-
Operating Temperature:
0°C~+70°C@(TA)
-
Synchronous Rectification:
NO
-
Package:
SOP-8
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Active
-
Output Configuration:
Positive
-
Voltage - Input (Min):
1.7V
-
Voltage - Input (Max):
12V
-
Voltage - Output (Min/Fixed):
1.7V
-
Voltage - Output (Max):
28V
-
Current - Output:
1A (Switch)
-
Frequency - Switching:
600kHz
-
Synchronous Rectifier:
No
-
Mounting Type:
Surface Mount
-
Package / Case:
8-SOIC (0.154", 3.90mm Width)
-
Supplier Device Package:
8-SOIC
-
Base Part Number:
LT1949
-
detail:
Boost, SEPIC Switching Regulator IC Positive Adjustable 1.7V 1 Output 1A (Switch) 8-SOIC (0.154", 3.90mm Width)
