LT1120IS8#PBF دیتاشیت

LT1120IS8#PBF

مشخصات دیتاشیت

نام دیتاشیت LT1120IS8#PBF
حجم فایل 87.251 کیلوبایت
نوع فایل pdf
تعداد صفحات 12

دانلود دیتاشیت LT1120IS8#PBF

دانلود دیتاشیت

سایر مستندات

LT1120 Datasheet 12 pages

مشخصات فنی

  • RoHS: true
  • Category: Power Supply Chip/Linear Voltage Regulators (LDO)
  • Datasheet: Analog Devices LT1120IS8#PBF
  • Output Type: Adjustable
  • Output Current: 125mA
  • Output Voltage: 2.5V~35.35V
  • Dropout Voltage: 0.65V@(125mA)
  • Output Polarity: positive
  • Number of Outputs: 1
  • Maximum Input Voltage: 36V
  • Operating Temperature: -40°C~+100°C
  • Quiescent Current (Ground Current): 80uA
  • Package: SOP-8
  • Manufacturer: Analog Devices
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Output Configuration: Positive
  • Number of Regulators: 1
  • Voltage - Input (Max): 36V
  • Voltage - Output (Min/Fixed): 2.5V
  • Voltage - Output (Max): 35.35V
  • Voltage Dropout (Max): 0.65V @ 125mA
  • Current - Output: 125mA
  • Current - Quiescent (Iq): 80µA
  • Current - Supply (Max): 100µA
  • PSRR: -
  • Control Features: Enable
  • Protection Features: Over Current, Over Temperature
  • Mounting Type: Surface Mount
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Supplier Device Package: 8-SOIC
  • Base Part Number: LT1120
  • detail: Linear Voltage Regulator IC 1 Output 125mA 8-SOIC
