LTC3106IFE#PBF دیتاشیت

مشخصات دیتاشیت

مشاهده دیتاشیت LTC3106IFE#PBF	دانلود دیتاشیت

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Buck-boost type
Topology: Step-down-Boost
Datasheet: Analog Devices LTC3106IFE#PBF
Output Type: Adjustable
Input Voltage: 0.85V~6V
Output Voltage: 1.8V;2.2V;3.3V;5V
Number of Outputs: 1
Switching Frequency: -
Output Current (Max): 300mA
Operating Temperature: -40°C~+125°C@(TJ)
Synchronous Rectification: Yes
Package: TSSOP-20-EP
Manufacturer: Analog Devices
Series: -
Packaging: Bulk
Part Status: Active
Output Configuration: Positive
Voltage - Input (Min): 0.85V
Voltage - Input (Max): 6V
Voltage - Output (Min/Fixed): 1.8V, 2.2V, 3.3V, 5V
Voltage - Output (Max): -
Current - Output: 300mA
Frequency - Switching: -
Synchronous Rectifier: Yes
Mounting Type: Surface Mount
Package / Case: 20-TSSOP (0.173", 4.40mm Width) Exposed Pad
Supplier Device Package: 20-TSSOP-EP
Base Part Number: LTC3106
detail: Buck-Boost Switching Regulator IC Positive Programmable 1.8V, 2.2V, 3.3V, 5V 1 Output 300mA 20-TSSOP (0.173", 4.40mm Width) Exposed Pad
