LT1950EGN#PBF دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
LT1950EGN#PBF
|
|
حجم فایل
|
110.318
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
20
|
مشخصات فنی
-
RoHS:
true
-
Category:
Power Supply Chip/AC-DC Controllers & Regulators
-
Topology:
Boost;Flyback;Forward;SEPIC
-
Datasheet:
Analog Devices LT1950EGN#PBF
-
Duty Cycle:
95%
-
Supply Voltage:
3V~25V
-
Switching Frequency:
100kHz~500kHz
-
Operating Temperature:
-40°C~+125°C@(TJ)
-
Package:
SSOP-16-150mil
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Tube
-
Part Status:
Active
-
Output Type:
Transistor Driver
-
Function:
Step-Up, Step-Up/Step-Down
-
Output Configuration:
Positive, Isolation Capable
-
Number of Outputs:
1
-
Output Phases:
1
-
Voltage - Supply (Vcc/Vdd):
3V ~ 25V
-
Frequency - Switching:
100kHz ~ 500kHz
-
Duty Cycle (Max):
95%
-
Synchronous Rectifier:
No
-
Clock Sync:
Yes
-
Serial Interfaces:
-
-
Control Features:
Enable, Frequency Control
-
Mounting Type:
Surface Mount
-
Package / Case:
16-SSOP (0.154", 3.90mm Width)
-
Supplier Device Package:
16-SSOP
-
Base Part Number:
LT1950
-
detail:
Boost, Flyback, Forward Converter, SEPIC Regulator Positive, Isolation Capable Output Step-Up, Step-Up/Step-Down DC-DC Controller IC 16-SSOP
