دیتاشیت MIC29501-3.3WT
مشخصات دیتاشیت
| نام دیتاشیت | MIC29150, MIC29300, MIC29500, MIC29750 |
|---|---|
| حجم فایل | 2666.054 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 42 |
دانلود دیتاشیت MIC29150, MIC29300, MIC29500, MIC29750 |
MIC29150, MIC29300, MIC29500, MIC29750 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/Linear Voltage Regulators (LDO)
- Datasheet: Microchip Tech MIC29501-3.3WT
- Output Type: Fixed
- Output Current: 5A
- Output Voltage: 3.3V
- Dropout Voltage: 600mV@(5A)
- Output Polarity: Positive
- Number of Outputs: 1
- Maximum Input Voltage: 26V
- Operating Temperature: -40°C~+125°C
- Power Supply Rejection Ratio (PSRR): -
- Package: TO-220-5
- Manufacturer: Microchip Tech
- Series: -
- Packaging: Tube
- Part Status: Active
- Output Configuration: Positive
- Number of Regulators: 1
- Voltage - Input (Max): 26V
- Voltage - Output (Min/Fixed): 3.3V
- Voltage - Output (Max): -
- Voltage Dropout (Max): 0.6V @ 5A
- Current - Output: 5A
- PSRR: -
- Control Features: Enable
- Protection Features: Over Current, Over Temperature, Reverse Polarity, Transient Voltage
- Mounting Type: Through Hole
- Package / Case: TO-220-5
- Supplier Device Package: TO-220-5
- Base Part Number: MIC29501-3.3
- detail: Linear Voltage Regulator IC 1 Output 5A TO-220-5
