LTC1380IS#PBF دیتاشیت

مشخصات دیتاشیت

دانلود دیتاشیت LTC1380IS#PBF	دانلود دیتاشیت

RoHS: true
Category: Communication Interface Chip/UART/485/232/Analog Switches / Multiplexers
Datasheet: Analog Devices LTC1380IS#PBF
Turn-on time: 1.5us
Turn-off time: 1.2us
Supply Voltage: 2.7V
Number of Channels: 1
On-State Resistance (Max): 70Ω
Package: SO-16
Manufacturer: Analog Devices
Series: -
Packaging: Tube
Part Status: Active
Switch Circuit: -
Multiplexer/Demultiplexer Circuit: 8:1
Number of Circuits: 1
Channel-to-Channel Matching (ΔRon): -
Voltage - Supply, Single (V+): 2.7V
Voltage - Supply, Dual (V±): ±5V
Switch Time (Ton, Toff) (Max): 1.5µs, 1.2µs
-3db Bandwidth: -
Charge Injection: 1pC
Channel Capacitance (CS(off), CD(off)): 3pF, 26pF
Current - Leakage (IS(off)) (Max): 5nA
Crosstalk: -
Operating Temperature: -40°C ~ 85°C (TA)
Mounting Type: Surface Mount
Package / Case: 16-SOIC (0.154", 3.90mm Width)
Supplier Device Package: 16-SOIC
Base Part Number: LTC1380
detail: 1 Circuit IC Switch 8:1 70Ohm 16-SOIC
