APT30M61SLLG/TR دیتاشیت
مشخصات دیتاشیت
|
نام دیتاشیت
|
APT30M61(B,S)LL
|
|
حجم فایل
|
105.986
کیلوبایت
|
|
نوع فایل
|
pdf
|
|
تعداد صفحات
|
5
|
مشخصات فنی
-
Manufacturer:
Microchip Technology
-
Series:
POWER MOS 7®
-
Packaging:
Cut Tape (CT)
-
Part Status:
Discontinued at Digi-Key
-
FET Type:
N-Channel
-
Technology:
MOSFET (Metal Oxide)
-
Drain to Source Voltage (Vdss):
300V
-
Current - Continuous Drain (Id) @ 25°C:
54A (Tc)
-
Drive Voltage (Max Rds On, Min Rds On):
10V
-
Rds On (Max) @ Id, Vgs:
61mOhm @ 27A, 10V
-
Vgs(th) (Max) @ Id:
5V @ 1mA
-
Gate Charge (Qg) (Max) @ Vgs:
64nC @ 10V
-
Vgs (Max):
±30V
-
Input Capacitance (Ciss) (Max) @ Vds:
3720pF/m @ 25V
-
FET Feature:
-
-
Power Dissipation (Max):
403W (Tc)
-
Operating Temperature:
-55°C ~ 150°C (TJ)
-
Mounting Type:
Surface Mount
-
Supplier Device Package:
D3PAK
-
Package / Case:
TO-268-3, D³Pak (2 Leads + Tab), TO-268AA
-
detail:
N-Channel 300V 54A (Tc) 403W (Tc) Surface Mount D3PAK
