دیتاشیت PIC18F4682-E/ML
مشخصات دیتاشیت
| نام دیتاشیت | PIC18F268x, 468x Data Sheet |
|---|---|
| حجم فایل | 8212.639 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 484 |
دانلود دیتاشیت PIC18F268x, 468x Data Sheet |
PIC18F268x, 468x Data Sheet Datasheet |
|---|
مشخصات
- RoHS: true
- EEPROM: 40KB
- CPU Core: PIC
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: -
- Watchdog: -
- ADC (Bit): 10bit
- DAC (Bit): -
- Datasheet: Microchip Tech PIC18F4682-E/ML
- PWM (Bit): -
- Real-Time Clock: -
- CPU Maximum Speed: 40MHz
- GPIO Ports Number: 36
- Low-Voltage Detect: -
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: Yes
- Peripheral/Function: PWM;WDT
- Program Memory Type: FLASH
- Direct Memory Access: -
- Program Storage Size: 40KB
- Universal Serial Bus: -
- communication protocol: -
- Operating Voltage Range: 4.2V~5.5V
- Infrared Data Association: -
- Operating Temperature Range: -40°C~+125°C
- Secure Digital Input and Output: -
- Package: QFN-44-EP(8x8)
- Manufacturer: Microchip Tech
- Series: PIC® 18F
- Packaging: Tube
- Part Status: Active
- Core Processor: PIC
- Core Size: 8-Bit
- Speed: 40MHz
- Connectivity: CANbus, I²C, SPI, UART/USART
- Peripherals: Brown-out Detect/Reset, HLVD, POR, PWM, WDT
- Number of I/O: 36
- Program Memory Size: 80KB (40K x 16)
- EEPROM Size: 1K x 8
- Voltage - Supply (Vcc/Vdd): 4.2V ~ 5.5V
- Data Converters: A/D 11x10b
- Oscillator Type: Internal
- Operating Temperature: -40°C ~ 125°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 44-VQFN Exposed Pad
- Supplier Device Package: 44-QFN (8x8)
- Base Part Number: PIC18F4682
- detail: PIC PIC® 18F Microcontroller IC 8-Bit 40MHz 80KB (40K x 16) FLASH 44-QFN (8x8)
