دیتاشیت LT1767EMS8E-1.8#PBF

مشخصات دیتاشیت

دانلود دیتاشیت LT1767(-1.8, 2.5, 3.3, 5) Datasheet	LT1767(-1.8, 2.5, 3.3, 5) Datasheet Datasheet

RoHS: true
Category: Power Supply Chip/DC-DC Converters
Function: Step-down type
Topology: Step-down;SEPIC
Datasheet: Analog Devices LT1767EMS8E-1.8#PBF
Output Type: Fixed
Input Voltage: 3V~25V
Output Voltage: 1.8V
Number of Outputs: 1
Switching Frequency: 1.25MHz
Output Current (Max): 1.5A
Operating Temperature: 0°C~+125°C@(TJ)
Synchronous Rectification: NO
Package: MSOP-8-EP
Manufacturer: Analog Devices
Series: -
Packaging: Tube
Part Status: Active
Output Configuration: Positive
Voltage - Input (Min): 3V
Voltage - Input (Max): 25V
Voltage - Output (Min/Fixed): 1.8V
Voltage - Output (Max): -
Current - Output: 1.5A
Frequency - Switching: 1.25MHz
Synchronous Rectifier: No
Mounting Type: Surface Mount
Package / Case: 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) Exposed Pad
Supplier Device Package: 8-MSOP-EP
Base Part Number: LT1767
detail: Buck, SEPIC Switching Regulator IC Positive Fixed 1.8V 1 Output 1.5A 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) Exposed Pad
