دیتاشیت LTC2642CMS-12#PBF

LTC2641, LTC2642 Datasheet

مشخصات دیتاشیت

نام دیتاشیت LTC2641, LTC2642 Datasheet
حجم فایل 306.305 کیلوبایت
نوع فایل pdf
تعداد صفحات 24

دانلود دیتاشیت LTC2641, LTC2642 Datasheet

LTC2641, LTC2642 Datasheet Datasheet

مشخصات

  • Manufacturer: Linear Technology/Analog Devices
  • Series: -
  • Packaging: Tube
  • Part Status: Active
  • Number of Bits: 12
  • Number of D/A Converters: 1
  • Settling Time: 1µs (Typ)
  • Output Type: Voltage - Unbuffered
  • Differential Output: No
  • Data Interface: SPI
  • Reference Type: External
  • Voltage - Supply, Analog: 2.7V ~ 5.5V
  • Voltage - Supply, Digital: 2.7V ~ 5.5V
  • INL/DNL (LSB): ±0.5 (Max), ±0.5 (Max)
  • Architecture: R-2R
  • Operating Temperature: 0°C ~ 70°C
  • Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
  • Supplier Device Package: 10-MSOP
  • Mounting Type: Surface Mount
  • Base Part Number: LTC2642
  • detail: 12 Bit Digital to Analog Converter 1 10-MSOP
