- دیتاشیت LTM2885CY#PBF
LTM2885CY#PBF دیتاشیت
مشخصات دیتاشیت
| نام دیتاشیت | LTM2885CY#PBF |
|---|---|
| حجم فایل | 128.087 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 22 |
دانلود دیتاشیت LTM2885CY#PBF |
دانلود دیتاشیت |
|---|
سایر مستندات
µModule Isolators Product Selector 8 pages
LTM2885 Datasheet 22 pages
مشخصات فنی
- RoHS: true
- Category: Communication Interface Chip/UART/485/232/Digital Isolators
- Data Rate: 20Mbps
- Datasheet: Analog Devices LTM2885CY#PBF
- Applications: RS422;RS485
- Supply Voltage: 4.5V~5.5V
- Forward Channel: 1
- Reverse channel: 1
- Number of Channels: 2
- Isolation Technology: Magnetic isolation
- Operating Temperature: 0°C~+70°C
- Voltage Isolation or Not: 带电压隔离
- Package: BGA-42
- Manufacturer: Analog Devices
- Series: µModule®
- Packaging: Tray
- Part Status: Active
- Technology: Magnetic Coupling
- Type: RS422, RS485
- Isolated Power: Yes
- Inputs - Side 1/Side 2: 1/1
- Channel Type: Unidirectional
- Voltage - Isolation: 6500Vrms
- Common Mode Transient Immunity (Min): 50kV/µs
- Propagation Delay tpLH / tpHL (Max): -
- Pulse Width Distortion (Max): -
- Rise / Fall Time (Typ): 4ns, 4ns
- Voltage - Supply: 4.5V ~ 5.5V
- Mounting Type: Surface Mount
- Package / Case: 42-BBGA
- Supplier Device Package: 42-BGA (22x9)
- Base Part Number: LTM2885
- detail: RS422, RS485 Digital Isolator 6500Vrms 2 Channel 20Mbps 50kV/µs CMTI 42-BBGA
