DS4301U-200+T&R Datasheet
Datasheet specifications
| Datasheet's name | DS4301 |
|---|---|
| File size | 153.775 KB |
| File type | |
| Number of pages | 7 |
Download Datasheet DS4301 |
Download Datasheet |
|---|
Other documentations
No other documentation was found!
Technical specifications
- Temperature Coefficient (Typ): ±250ppm/°C
- Features: -
- Supplier Device Package: 8-uMAX
- Configuration: Potentiometer
- Resistance (Ohms): 200k
- Tolerance: ±20%
- Package / Case: 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
- Resistance - Wiper (Ohms) (Typ): 500
- Part Status: Active
- Voltage - Supply: 2.4V ~ 5.5V
- Operating Temperature: -40°C ~ 85°C
- Number of Taps: 32
- Series: -
- Interface: Up/Down (U/D, INC, CS)
- Taper: Linear
- Mounting Type: Surface Mount
- Number of Circuits: 1
- Packaging: Tube
- Memory Type: Non-Volatile
- Base Part Number: DS4301
- Manufacturer: Maxim Integrated
- detail: Digital Potentiometer 200k Ohm 1 Circuit 32 Taps Up/Down (U/D, INC, CS) Interface 8-uMAX
