دیتاشیت AT91SAM9XE256B-CU
مشخصات دیتاشیت
| نام دیتاشیت | SAM9XE Series |
|---|---|
| حجم فایل | 3534.202 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 877 |
دانلود دیتاشیت SAM9XE Series |
SAM9XE Series Datasheet |
|---|
مشخصات
- CAN: -
- I2C: -
- I2S: -
- SPI: -
- RoHS: true
- EEPROM: -
- CPU Core: ARMOther series
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: -
- Watchdog: -
- ADC (Bit): -
- DAC (Bit): -
- Datasheet: Microchip Tech AT91SAM9XE256B-CU
- PWM (Bit): -
- 8Bit Timer: -
- LCD Module: Yes
- UART/USART: -
- 16Bit Timer: -
- 32Bit Timer: -
- Real-Time Clock: -
- CPU Maximum Speed: 180MHz
- GPIO Ports Number: -
- Low-Voltage Detect: -
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: -
- Peripheral/Function: Ethernet protocol stack
- Program Memory Type: -
- Direct Memory Access: -
- Program Storage Size: -
- Universal Serial Bus: Yes
- communication protocol: 以太网协议
- Operating Voltage Range: -
- Infrared Data Association: -
- Operating Temperature Range: -40°C~+85°C
- Secure Digital Input and Output: -
- Package: LFBGA-217
- Manufacturer: Microchip Tech
- Series: SAM9XE
- Packaging: Tray
- Part Status: Active
- Core Processor: ARM926EJ-S
- Number of Cores/Bus Width: 1 Core, 32-Bit
- Speed: 180MHz
- Co-Processors/DSP: -
- RAM Controllers: SDRAM, SRAM
- Graphics Acceleration: No
- Display & Interface Controllers: LCD, Touchscreen
- Ethernet: 10/100Mbps
- SATA: -
- USB: USB 2.0 (3)
- Voltage - I/O: 1.8V, 2.5V, 3.3V
- Operating Temperature: -40°C ~ 85°C (TA)
- Security Features: -
- Package / Case: 217-LFBGA
- Supplier Device Package: 217-LFBGA (15x15)
- Additional Interfaces: EBI/EMI, I²C, ISI, MMC/SD/SDIO, SPI, SSC, UART/USART
- Base Part Number: AT91SAM9XE256
- detail: ARM926EJ-S Microprocessor IC SAM9XE 1 Core, 32-Bit 180MHz 217-LFBGA (15x15)
