دیتاشیت ATZB-S1-256-3-0-CR

مشخصات دیتاشیت

دانلود دیتاشیت ATZB-S1-256-3-0-C~	ATZB-S1-256-3-0-C~ Datasheet

Manufacturer: Microchip Technology
Series: ZigBit™
Packaging: Cut Tape (CT)
Part Status: Discontinued at Digi-Key
RF Family/Standard: 802.15.4
Protocol: Zigbee®
Modulation: -
Frequency: 2.4GHz
Data Rate: 2Mbps
Power - Output: 3.5dBm
Sensitivity: -97dBm
Serial Interfaces: ISP, JTAG, SPI, UART, USART
Antenna Type: Integrated, Chip
Utilized IC / Part: -
Memory Size: 256kB Flash, 8kB EEPROM, 32kB SRAM
Voltage - Supply: 1.8V ~ 3.6V
Current - Receiving: 9.6mA ~ 17mA
Current - Transmitting: 9.9mA ~ 16.3mA
Mounting Type: Surface Mount
Operating Temperature: -40°C ~ 85°C
Package / Case: Module
detail: 802.15.4 Zigbee® Transceiver Module 2.4GHz Integrated, Chip Surface Mount
