دیتاشیت LTC3547EDDB-1#TRMPBF
مشخصات دیتاشیت
| نام دیتاشیت | LTC3547 |
|---|---|
| حجم فایل | 309.505 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 16 |
دانلود دیتاشیت LTC3547 |
LTC3547 Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: Step-down type
- Topology: Step-down
- Datasheet: Analog Devices LTC3547EDDB-1#TRMPBF
- Output Type: Fixed
- Input Voltage: 2.5V~5.5V
- Number of Outputs: 2
- Switching Frequency: 2.25MHz
- Output Current (Max): 300mA
- Operating Temperature: -40°C~+85°C@(TA)
- Synchronous Rectification: Yes
- Package: DFN-8(2x3)
- Manufacturer: Analog Devices
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Discontinued at Digi-Key
- Output Configuration: Positive
- Voltage - Input (Min): 2.5V
- Voltage - Input (Max): 5.5V
- Voltage - Output (Min/Fixed): 1.2V, 1.8V
- Voltage - Output (Max): -
- Current - Output: 300mA
- Frequency - Switching: 2.25MHz
- Synchronous Rectifier: Yes
- Mounting Type: Surface Mount
- Package / Case: 8-WFDFN Exposed Pad
- Supplier Device Package: 8-DFN (3x2)
- Base Part Number: LTC3547
- detail: Buck Switching Regulator IC Positive Fixed 1.2V, 1.8V 2 Output 300mA 8-WFDFN Exposed Pad
