دیتاشیت LTC3548EDD#TRPBF
مشخصات دیتاشیت
| نام دیتاشیت |
LTC3548
|
| حجم فایل |
254.55
کیلوبایت
|
| نوع فایل |
pdf
|
| تعداد صفحات |
16
|
مشخصات
-
RoHS:
true
-
Category:
Power Supply Chip/DC-DC Converters
-
Function:
Step-down type;Buck-boost type
-
Topology:
Step-down;Step-down-Boost
-
Datasheet:
Analog Devices LTC3548EDD#TRPBF
-
Output Type:
Adjustable
-
Input Voltage:
2.5V~5.5V
-
Output Voltage:
0.6V~5V
-
Number of Outputs:
2
-
Switching Frequency:
2.25MHz
-
Output Current (Max):
400mA;800mA
-
Operating Temperature:
-40°C~+85°C@(TA)
-
Synchronous Rectification:
Yes
-
Package:
DFN-10(3x3)
-
Manufacturer:
Analog Devices
-
Series:
-
-
Packaging:
Cut Tape (CT)
-
Part Status:
Active
-
Output Configuration:
Positive
-
Voltage - Input (Min):
2.5V
-
Voltage - Input (Max):
5.5V
-
Voltage - Output (Min/Fixed):
0.6V
-
Voltage - Output (Max):
5V
-
Current - Output:
400mA, 800mA
-
Frequency - Switching:
2.25MHz
-
Synchronous Rectifier:
Yes
-
Mounting Type:
Surface Mount
-
Package / Case:
10-WFDFN Exposed Pad
-
Supplier Device Package:
10-DFN (3x3)
-
Base Part Number:
LTC3548
-
detail:
Buck, Buck-Boost Switching Regulator IC Positive Adjustable 0.6V 2 Output 400mA, 800mA 10-WFDFN Exposed Pad
