دیتاشیت LTC3805EMSE#TRPBF
مشخصات دیتاشیت
| نام دیتاشیت | LTC3805 Datasheet |
|---|---|
| حجم فایل | 268.339 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 20 |
دانلود دیتاشیت LTC3805 Datasheet |
LTC3805 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Controllers
- Function: Buck-boost type
- Topology: Flyback
- Datasheet: Analog Devices LTC3805EMSE#TRPBF
- Input Voltage: 3.95V~9.5V
- Duty Cycle (Max): 80%
- Number of Outputs: 1
- Switching Frequency: 700kHz
- Operating Temperature: -40°C~+85°C@(TA)
- Synchronous Rectification: NO
- Package: MSOP-10-EP
- Manufacturer: Analog Devices
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Output Type: Transistor Driver
- Output Configuration: Positive, Isolation Capable
- Output Phases: 1
- Voltage - Supply (Vcc/Vdd): 3.95V ~ 9.5V
- Frequency - Switching: 70kHz ~ 700kHz
- Synchronous Rectifier: No
- Clock Sync: Yes
- Serial Interfaces: -
- Control Features: Enable, Soft Start
- Mounting Type: Surface Mount
- Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width) Exposed Pad
- Supplier Device Package: 10-MSOP-EP
- Base Part Number: LTC3805
- detail: Flyback Regulator Positive, Isolation Capable Output Step-Up/Step-Down DC-DC Controller IC 10-MSOP-EP
