دیتاشیت LTC1772IS6#TRMPBF

مشخصات دیتاشیت

دانلود دیتاشیت LTC1772	LTC1772 Datasheet

RoHS: true
Category: Power Supply Chip/DC-DC Controllers
Function: boost converterType;Step-down type;Buck-boost type
Topology: Step-down;Boost;Flyback
Datasheet: Analog Devices LTC1772IS6#TRMPBF
Input Voltage: 2.5V~9.8V
Duty Cycle (Max): 100%
Number of Outputs: 1
Switching Frequency: 550kHz
Operating Temperature: -40°C~+85°C@(TA)
Synchronous Rectification: NO
Package: SOT-23-6
Manufacturer: Analog Devices
Series: -
Packaging: Cut Tape (CT)
Part Status: Active
Output Type: Transistor Driver
Output Configuration: Positive
Output Phases: 1
Voltage - Supply (Vcc/Vdd): 2.5V ~ 9.8V
Frequency - Switching: 550kHz
Synchronous Rectifier: No
Clock Sync: No
Serial Interfaces: -
Control Features: Enable
Mounting Type: Surface Mount
Package / Case: SOT-23-6 Thin, TSOT-23-6
Supplier Device Package: TSOT-23-6
Base Part Number: LTC1772
detail: Buck, Boost, Flyback Regulator Positive Output Step-Up, Step-Down, Step-Up/Step-Down DC-DC Controller IC TSOT-23-6
