دیتاشیت AT94K40AL-25DQU
مشخصات دیتاشیت
| نام دیتاشیت | AT94K(05,10,40)AL |
|---|---|
| حجم فایل | 1570.08 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 192 |
دانلود دیتاشیت AT94K(05,10,40)AL |
AT94K(05,10,40)AL Datasheet |
|---|
مشخصات
- CAN: -
- I2C: -
- I2S: -
- SPI: -
- RoHS: true
- EEPROM: -
- CPU Core: AVR
- Category: Single Chip Microcomputer/Microcontroller/Microcontroller Units (MCUs/MPUs/SOCs)
- RAM Size: -
- Watchdog: -
- ADC (Bit): -
- DAC (Bit): -
- Datasheet: Microchip Tech AT94K40AL-25DQU
- PWM (Bit): -
- 8Bit Timer: -
- UART/USART: -
- 16Bit Timer: -
- 32Bit Timer: -
- Real-Time Clock: -
- CPU Maximum Speed: 18MHz
- GPIO Ports Number: -
- Low-Voltage Detect: -
- CCP Capture/Compare: -
- Internal Comparator: -
- Internal Oscillator: -
- Peripheral/Function: -
- Program Memory Type: -
- Direct Memory Access: -
- Program Storage Size: -
- Universal Serial Bus: -
- communication protocol: -
- Operating Voltage Range: 3V~3.6V
- Infrared Data Association: -
- Operating Temperature Range: -40°C~+85°C
- Secure Digital Input and Output: -
- Package: PQFP-208(28x28)
- Manufacturer: Microchip Tech
- Series: FPSLIC®
- Packaging: Tray
- Part Status: Active
- Core Type: 8-Bit AVR
- Speed: 18MHz
- Interface: I²C, UART
- Program SRAM Bytes: 20K-32K
- FPGA SRAM: 18kb
- EEPROM Size: -
- Data SRAM Bytes: 4K ~ 16K
- FPGA Core Cells: 2304
- FPGA Gates: 40K
- FPGA Registers: 2862
- Voltage - Supply: 3V ~ 3.6V
- Mounting Type: Surface Mount
- Operating Temperature: -40°C ~ 85°C
- Package / Case: 208-BFQFP
- Supplier Device Package: 208-PQFP (28x28)
- detail: IC FPSLIC 40K GATE 25MHZ 208QFP
