- دیتاشیت LT3489EMS8E#TRPBF
دیتاشیت LT3489EMS8E#TRPBF
مشخصات دیتاشیت
| نام دیتاشیت | LT3489EMS8E#TRPBF |
|---|---|
| حجم فایل | 87.528 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 12 |
LT3489EMS8E#TRPBF |
دانلود دیتاشیت |
|---|
سایر مستندات
LT3489 12 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: boost converterType
- Topology: Boost
- Datasheet: Analog Devices LT3489EMS8E#TRPBF
- Output Type: Adjustable
- Input Voltage: 2.6V~16V
- Output Voltage: 2.6V~40V
- Number of Outputs: 1
- Switching Frequency: 2MHz
- Output Current (Max): 2.5A
- Operating Temperature: -40°C~+85°C@(TA)
- Synchronous Rectification: NO
- Package: MSOP-8-EP
- Manufacturer: Analog Devices
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Output Configuration: Positive
- Voltage - Input (Min): 2.6V
- Voltage - Input (Max): 16V
- Voltage - Output (Min/Fixed): 2.6V
- Voltage - Output (Max): 40V (Switch)
- Current - Output: 2.5A (Switch)
- Frequency - Switching: 2MHz
- Synchronous Rectifier: No
- Mounting Type: Surface Mount
- Package / Case: 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) Exposed Pad
- Supplier Device Package: 8-MSOP-EP
- Base Part Number: LT3489
- detail: Boost Switching Regulator IC Positive Adjustable 2.6V 1 Output 2.5A (Switch) 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) Exposed Pad
