دیتاشیت LT8609AEMSE#TRPBF
مشخصات دیتاشیت
| نام دیتاشیت | LT8609(A, B) Datasheet |
|---|---|
| حجم فایل | 2031.078 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 30 |
دانلود دیتاشیت LT8609(A, B) Datasheet |
LT8609(A, B) Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: Step-down type
- Topology: Step-down
- Datasheet: Analog Devices LT8609AEMSE#TRPBF
- Output Type: Adjustable
- Input Voltage: 3V~42V
- Output Voltage: 0.782V~42V
- Number of Outputs: 1
- Switching Frequency: 2.2MHz
- Output Current (Max): 3A
- Operating Temperature: -40°C~+125°C@(TJ)
- Synchronous Rectification: Yes
- Package: MSOP-10-EP
- Manufacturer: Analog Devices
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Output Configuration: Positive
- Voltage - Input (Min): 3V
- Voltage - Input (Max): 42V
- Voltage - Output (Min/Fixed): 0.782V
- Voltage - Output (Max): 42V
- Current - Output: 3A
- Frequency - Switching: 200kHz ~ 2.2MHz
- Synchronous Rectifier: Yes
- Mounting Type: Surface Mount
- Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width) Exposed Pad
- Supplier Device Package: 10-MSOP-EP
- Base Part Number: LT8609
- detail: Buck Switching Regulator IC Positive Adjustable 0.782V 1 Output 3A 10-TFSOP, 10-MSOP (0.118", 3.00mm Width) Exposed Pad
