دیتاشیت APT10035B2FLLG

APT10035(B2,L)FLL(G)

مشخصات دیتاشیت

نام دیتاشیت APT10035(B2,L)FLL(G)
حجم فایل 185.884 کیلوبایت
نوع فایل pdf
تعداد صفحات 5

دانلود دیتاشیت APT10035(B2,L)FLL(G)

APT10035(B2,L)FLL(G) Datasheet

مشخصات

  • Manufacturer: Microchip Technology
  • Series: POWER MOS 7®
  • Packaging: Tube
  • Part Status: Active
  • FET Type: N-Channel
  • Technology: MOSFET (Metal Oxide)
  • Drain to Source Voltage (Vdss): 1000V
  • Current - Continuous Drain (Id) @ 25°C: 28A (Tc)
  • Drive Voltage (Max Rds On, Min Rds On): 10V
  • Rds On (Max) @ Id, Vgs: 370mOhm @ 14A, 10V
  • Vgs(th) (Max) @ Id: 5V @ 2.5mA
  • Gate Charge (Qg) (Max) @ Vgs: 186nC @ 10V
  • Vgs (Max): ±30V
  • Input Capacitance (Ciss) (Max) @ Vds: 5185pF @ 25V
  • FET Feature: -
  • Power Dissipation (Max): 690W (Tc)
  • Operating Temperature: -55°C ~ 150°C (TJ)
  • Mounting Type: Through Hole
  • Supplier Device Package: T-MAX™ [B2]
  • Package / Case: TO-247-3 Variant
  • detail: N-Channel 1000V 28A (Tc) 690W (Tc) Through Hole T-MAX™ [B2]
