دیتاشیت LTC1871EMS-7#TRPBF
مشخصات دیتاشیت
| نام دیتاشیت | LTC1871-7 Datasheet |
|---|---|
| حجم فایل | 397.535 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 34 |
دانلود دیتاشیت LTC1871-7 Datasheet |
LTC1871-7 Datasheet Datasheet |
|---|
مشخصات
- Manufacturer: Linear Technology/Analog Devices
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Output Type: Transistor Driver
- Function: Step-Up, Step-Up/Step-Down
- Output Configuration: Positive
- Topology: Boost, Flyback, SEPIC
- Number of Outputs: 1
- Output Phases: 1
- Voltage - Supply (Vcc/Vdd): 6V ~ 36V
- Frequency - Switching: 50kHz ~ 1MHz
- Duty Cycle (Max): 92%
- Synchronous Rectifier: No
- Clock Sync: Yes
- Serial Interfaces: -
- Control Features: Enable, Frequency Control
- Operating Temperature: -40°C ~ 85°C (TA)
- Mounting Type: Surface Mount
- Package / Case: 10-TFSOP, 10-MSOP (0.118", 3.00mm Width)
- Supplier Device Package: 10-MSOP
- Base Part Number: LTC1871
- detail: Boost, Flyback, SEPIC Regulator Positive Output Step-Up, Step-Up/Step-Down DC-DC Controller IC 10-MSOP
