دیتاشیت LTC1778EGN-1#TRPBF
مشخصات دیتاشیت
| نام دیتاشیت | LTC1778(-1) Datasheet |
|---|---|
| حجم فایل | 273.177 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 24 |
دانلود دیتاشیت LTC1778(-1) Datasheet |
LTC1778(-1) Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Controllers
- Function: Step-down type;Buck-boost type
- Topology: Step-down;Step-down-Boost
- Datasheet: Analog Devices LTC1778EGN-1#TRPBF
- Input Voltage: 4V~36V
- Duty Cycle (Max): -
- Number of Outputs: 1
- Switching Frequency: -
- Operating Temperature: -40°C~+85°C@(TA)
- Synchronous Rectification: Yes
- Package: SSOP-16-150mil
- Manufacturer: Analog Devices
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Output Type: Transistor Driver
- Output Configuration: Positive or Negative
- Output Phases: 1
- Voltage - Supply (Vcc/Vdd): 4V ~ 36V
- Frequency - Switching: -
- Synchronous Rectifier: Yes
- Clock Sync: Yes
- Serial Interfaces: -
- Control Features: Enable, Power Good, Soft Start
- Mounting Type: Surface Mount
- Package / Case: 16-SSOP (0.154", 3.90mm Width)
- Supplier Device Package: 16-SSOP
- Base Part Number: LTC1778
- detail: Buck, Buck-Boost Regulator Positive or Negative Output Step-Down, Step-Up/Step-Down DC-DC Controller IC 16-SSOP
