دیتاشیت LT1004CS8-1.2#TRPBF

LT1004 Datasheet

مشخصات دیتاشیت

نام دیتاشیت LT1004 Datasheet
حجم فایل 683.517 کیلوبایت
نوع فایل pdf
تعداد صفحات 12

دانلود دیتاشیت LT1004 Datasheet

LT1004 Datasheet Datasheet

مشخصات

  • Manufacturer: Linear Technology/Analog Devices
  • Series: -
  • Packaging: Cut Tape (CT)
  • Part Status: Active
  • Reference Type: Shunt
  • Output Type: Fixed
  • Voltage - Output (Min/Fixed): 1.235V
  • Current - Output: 20mA
  • Tolerance: ±0.3%
  • Temperature Coefficient: 20ppm/°C Typical
  • Noise - 0.1Hz to 10Hz: -
  • Noise - 10Hz to 10kHz: 60µVrms
  • Voltage - Input: -
  • Current - Supply: -
  • Current - Cathode: 10µA
  • Operating Temperature: 0°C ~ 70°C (TA)
  • Mounting Type: Surface Mount
  • Package / Case: 8-SOIC (0.154", 3.90mm Width)
  • Supplier Device Package: 8-SOIC
  • Base Part Number: LT1004
  • detail: Shunt Voltage Reference IC ±0.3% 8-SOIC
