- دیتاشیت LTpowerCAD II User Guide
دیتاشیت LTpowerCAD II User Guide
مشخصات دیتاشیت
| نام دیتاشیت | LTpowerCAD II User Guide |
|---|---|
| حجم فایل | 5376.71 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 60 |
LTpowerCAD II User Guide |
دانلود دیتاشیت |
|---|
سایر مستندات
LT8331 Datasheet 30 pages
LT8331IMSE#TRPBF 30 pages
مشخصات فنی
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: boost converterType;Buck-boost type
- Topology: Boost;Flyback;SEPIC
- Datasheet: Analog Devices LT8331EMSE#TRPBF
- Output Type: Adjustable
- Input Voltage: 4.5V~100V
- Output Voltage: 1.6V;-0.8V~140V
- Number of Outputs: 1
- Switching Frequency: 500kHz
- Output Current (Max): 500mA
- Operating Temperature: -40°C~+125°C@(TJ)
- Synchronous Rectification: NO
- Package: MSOP-12
- Manufacturer: Analog Devices
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Output Configuration: Positive or Negative, Isolation Capable
- Voltage - Input (Min): 4.5V
- Voltage - Input (Max): 100V
- Voltage - Output (Min/Fixed): 1.6V, -0.8V
- Voltage - Output (Max): 140V (Switch)
- Current - Output: 500mA (Switch)
- Frequency - Switching: 100kHz ~ 500kHz
- Synchronous Rectifier: No
- Mounting Type: Surface Mount
- Package / Case: 16-TFSOP (0.118", 3.00mm Width) Exposed Pad, 12 Leads
- Supplier Device Package: 16-MSOP-EP
- Base Part Number: LT8331
- detail: Boost, Flyback, SEPIC Switching Regulator IC Positive or Negative, Isolation Capable Adjustable 1.6V, -0.8V 1 Output 500mA (Switch) 16-TFSOP (0.118", 3.00mm Width) Exposed Pad, 12 Leads
