دیتاشیت LT1776IS8#TRPBF
مشخصات دیتاشیت
| نام دیتاشیت | LT1776 Datasheet |
|---|---|
| حجم فایل | 234.956 کیلوبایت |
| نوع فایل | |
| تعداد صفحات | 20 |
دانلود دیتاشیت LT1776 Datasheet |
LT1776 Datasheet Datasheet |
|---|
مشخصات
- RoHS: true
- Category: Power Supply Chip/DC-DC Converters
- Function: Step-down type
- Topology: Step-down
- Datasheet: Analog Devices LT1776IS8#TRPBF
- Output Type: Adjustable
- Input Voltage: 7.4V~40V
- Output Voltage: 1.24V~34V
- Number of Outputs: 1
- Switching Frequency: 200kHz
- Output Current (Max): 550mA
- Operating Temperature: -40°C~+125°C@(TJ)
- Synchronous Rectification: NO
- Package: SOIC-8
- Manufacturer: Analog Devices
- Series: -
- Packaging: Cut Tape (CT)
- Part Status: Active
- Output Configuration: Positive
- Voltage - Input (Min): 7.4V
- Voltage - Input (Max): 40V
- Voltage - Output (Min/Fixed): 1.24V
- Voltage - Output (Max): 34V
- Current - Output: 550mA (Switch)
- Frequency - Switching: 200kHz
- Synchronous Rectifier: No
- Mounting Type: Surface Mount
- Package / Case: 8-SOIC (0.154", 3.90mm Width)
- Supplier Device Package: 8-SOIC
- Base Part Number: LT1776
- detail: Buck Switching Regulator IC Positive Adjustable 1.24V 1 Output 550mA (Switch) 8-SOIC (0.154", 3.90mm Width)
